Anticon 100® StandardWeight™

Polyester wipe

Back to our polyester wipes

Anticon 100® StandardWeight™ wipes from CONTEC® are made from 100% polyester filaments as a double knitted interlock construction. The clean cut edges have low particle and fiber generation to minimize contamination. Using patented textile technology, Anticon 100® StandardWeight™ wipes achieve a fast absorption rate, making them an excellent choice for wiping and absorbing spills in critical cleanroom environments.

Facts

Particle emission (dry)
Particle emission (wet)
Abrasion resistance
Wet cleaning
Dry cleaning
Chemical permanence
Electrostatic behaviour
Softness
Sealed edges
decontaminated
sterile

Polyester

Anticon 100® StandardWeight™

Interlock knit, 100% PES, cold cut edges

-
-

Properties

  • 100% polyester
  • double-knit interlock fabric made of filaments
  • cold cut edges
  • chemically resistant
  • decontaminated in a cleanroom laundry
  • double bag packed in a cleanroom (air cleanliness class ISO 4)

Advantages

  • robust wipe fabric
  • very wide range of applications
  • low ionic and metallic impurities

Applications

  • cleaning wipe for both critical and non-critical areas
  • well suited for angular, rough surfaces and objects that might damage a non-woven wipe



Product recommen­dation based on cleanroom classes


123456789low dust


ABCDE

Of course, cleanroom wipes used in ISO 5 can also be used in ISO 9, but in this case the economic efficiency and usefulness should be considered.

A 1 to 1 allocation of cleanroom wipes to an air cleanliness class according to ISO 14644-1 is not possible. Recommendations can only be made on the basis of special properties relevant from a cleanroom technical point of view, such as "abrasion resistance" or "particle emission". Users can find further information on this in VDI Guideline 2083 Part 9.2.

Technische Daten

Properties   Unit of measurementValueTest method
Material     100% PES
Edge processing     cold cut
Surface weight   g/m2 120
Absorption capacity
(Ai) intrinsic
(Ae) extrinsic

ml/g
ml/m2

2,87
339
IEST-RP-CC004.3
Section 8.1
NVR
Non-volatile residues
IPA based
DI water based
µg/cm2
µg/cm2
0.08
0.04
IEST-RP-CC004.3
Section 7.1.1
Particulate residues ≥ 0.5 µm x 103/cm2 0.397 IEST-RP-CC004.3
Sec. 6.1.3
Biaxial Shake Test and LPC
Fibre residues ≥ 100 µm fibres/cm2 0.1558 IEST-RP-CC004.3
Sec. 6.2.2
Optical and Scanning Electron Microscopy
Ionic residues Sodium (Na)+
Chloride (Cl)-
ppm
ppm
0.184
0.030
IEST-RP-CC004.3
Section 7.2.2
Organic contaminants silicone oil
amides
D-n-octylphthalate (DOP)
  n. s.
n. s.
n. s.
by FTIR spectrometer
Fourier transform infrared spectrometer
  SizePU/CartonsubpackedArt. No.
  9" x 9"
12" x 12"
1,200
400
8 bags à 150 wipes
4 bags à 100 wipes
51MI-495352B
51MI-495352
      n. s. = not specified
n. d. = not detectable


Note

The manufacturer's technical data listed above are typical values at the time of publication. They are not specifications. All data are without guarantee, changes are possible without prior notice.
Due to different test methods depending on the respective manufacturers and test laboratories, most of the given values cannot be compared one-to-one with those of other manufacturers/wipes.
Independent tests can be commissioned on request.
